Neo Bicycles Neo Boys Geared 20-inch
Details
The Neo+ 20 6s Boy’s introduces the use of gears. The ideal bike for kids moving up from a smaller sized bike who can ride confidently, and are ready for the next challenge. This model features 6 speed gears, and allows kids to tackle hills and longer rides, while giving kids more control over their speed.
To boost rider confidence, we use short brake levers for easy and smooth braking, along with a low stand over frame design so kids can easily touch the ground when they need to.
Features:
- New child-specific frame with light weight oversized thin-wall alloy, hydroformed tubes and new streamline stays.
- Light weight alloy straight blade fork.
- Low stand over frame, allowing easy operation, boosting rider confidence and safety.
- Light weight alloy hubs, rims, handlebars and stem, which reduces the overall weight of the bicycle.
- Super comfortable child specific saddle and grips, for ultimate riding comfort.
- Light weight alloy crank set with child-specific easy pedaling gearing.
- Shimano 6 speed shifting for reliable shifting performance.
- Full alloy child-specific short reach brake levers
| MIN. SADDLE HEIGHT (TO GROUND) | 590 |
|---|---|
| MAX. SADDLE HEIGHT (TO GROUND) | 685 |
| A - SEAT TUBE (CENTRE TO TOP) | 240 |
| B - TOP TUBE LENGTH | 457 |
| C - SEAT ANGLE | 72.0° |
| D - HEAD ANGLE | 70.0° |
| E - FORK RAKE | 40 |
| F - WHEEL BASE | 891 |
| G - STAND OVER HEIGHT (TOP TUBE TO GROUND) | 520 |
| H - CHAIN STAY LENGTH | 375 |
| I - HEAD TUBE LENGTH | 100 |
| J - BB DROP | 0 |
| DROPOUT SPACING | 130 |
Specs
| Frame | Lightweight, easy to ride alloy kids frame, with low stand over height, new hydroformed tubes and streamline stays |
|---|---|
| Fork | 20" integrated lightweight rigid 6061 alloy fork with 25.4 straight blades |
| Wheels | 20" lightweight alloy 32 hole rims with alloy hubs with nutted axles |
| Tires | 20" x 1.75 slick |
| Bottom Bracket | Nutted bottom bracket |
| Crankset | Alloy oversize 3 piece crank with 36T chainwheel and double chainguard |
| Cassette/Freewheel | Shimano MF TZ06 14-28T 6 speed freewheel |
| Brakes | Alloy linear pull brakes, short reach alloy lever for kids |
| Handlebars | Lightweight alloy low riser 560mm |
| Tape/Grips | Kraton grips |
| Stem | Alloy A-head 4 bolt stem with Rise: 10° Bore: 25.4mm, L: 60mm. |
| Seatpost | 22.2mm alloy with quick release clamp |
| Saddle | Neo Comfortech youth saddle |
| Pedals | High impact plastic |
| Accessories & Extras | Kickstand |
* Subject to change without notice.
